30. Notifications

30.1. What is a notification ?

A notification is a message that Android displays outside your app’s UI to provide the user with reminders, communication from other people, or other timely information from your app.

30.2. Why is a notification ?

  • To notify the user if there is trigger of the data from the background services.
  • It let the user to know about the messages or any updates about the applications along with the actions.
  • User may know about the triggers without going into the application.
  • Also will send the live changes like temperature ,time ,date and location.

30.3. History of Notification :

  • This Notifications are started from the android version 4.4 (Kitkat).
  • For every new version released there is a much evaluation in the design,style,text ,icons for the notification.
  • It becomes more effective and efficient for the user to work with it.
  • Now it is also coming with the notifications dots to make use have the fast interaction with the applications easily.

30.4. How is a Notification ?

  • Notification is created and build using the Notification Service,Notification Manager and Notification Compat.
  • Upto Android version 7 (Nougat) all this tools are same but from the Android version 8 (Oreo) a new built in tool is introduced and named as Notification Channel under the Android Jetpack Components.

30.4.1. Building a notification upto Android 7(Nougat) :

NotificationManager manager = (NotificationManager)getSystemService(NOTIFICATION_SERVICE );
 NotificationCompat.Builder builder = new NotificationCompat.Builder(this)
           .setSmallIcon(R.drawable.android_icon)
           .setContentTitle("You've been notified!")
           .setContentText("This is your notification text")
	.setPriority(NotificationCompat.PRIORITY_HIGH);
manager.notify(ID,builder.build());

30.4.2. Building a notification for above Android 8(Oreo) :

 if (android.os.Build.VERSION.SDK_INT >= android.os.Build.VERSION_CODES.O) {
            NotificationChannel channel = new NotificationChannel("Cherry","APSSDC",
                    NotificationManager.IMPORTANCE_HIGH);
            channel.enableLights(true);
            channel.enableVibration(true);
            channel.setLightColor(Color.GREEN);
            manager.createNotificationChannel(channel);
        }

30.4.3. Importance level and priority contraints :

  • Below table represents the imporatance levels and contraints for Android 7(& Below) and Android 8(& Above) :

30.4.3.1. Creating Intent and Pending Intent in the Notification :

  • Intent will be created to build the connectivity between the notification and the java class ,to navigate when clicked on notification.
Intent intent = Intent(this, MainActivity.class);
  • Pending Intent will be created to connect the intent and the update type along with the notification id.
PendingIntent pendingIntent = PendingIntent.getActivity(this,NOTIFICATION_ID,intent,PendingIntent.FLAG_UPDATE_CURRENT);

30.5. Updating a Notification :

  • Update a notification by changing and or adding some of its content.
  • Issue notification with updated parameters using builder.
  • Call notify() passing in the same notification ID.
    • If previous notification is still visible, system updates.
    • If previous notification has been dismissed, new notification is delivered.

30.6. Cancelling a Notification :

Notifications remain visible until:

  • User dismisses it by swiping or by using “Clear All”.
  • Calling setAutoCancel() when creating the notification, removes it from the status bar when the user clicks on it.
  • App calls cancel() or cancelAll() on NotificationManager.
manager.cancel(NOTIFICATION_ID);
